Product characteristics
The design of the hydraulic cylinder / air cylinder is front-mounted, eliminating the need for additional installation of a rotary cylinder.
It features a forced discharging design, ensuring 100% no material jamming and easy installation.
It enables rapid clamping. With an enlarged cylinder body, it has a large clamping force.
It has high working flexibility. The auxiliary jaws can be quickly replaced, and it can clamp workpieces of various shapes.
The chuck is designed with a central through hole, and it is designed with a large stroke to cooperate with the automatic feeding system.
The opening stroke is 2.5mm, and a 50mm opening stroke can be customized.
It has a large through hole and can hold a maximum diameter of 500mm.
It allows continuous loading and unloading of materials, resulting in high productivity and is suitable for mass production.
It is driven to rotate by a motor, and synchronous pulleys / gears can be equipped at the rear.
The cutting fluid should not be directly sprayed towards the chuck.
